Planet Dişli Redüktörler (PT)
- Size: | 062 | 076 | 101 | 141 | 182 | 242 |
- Gear ratio range: (3) 4 to 100
- Max. torsional backlash (1-stage) ≤ 6 to ≤ 4 arcmin
- Red. torsional backlash (1-stage) ≤ 3 to ≤ 2 arcmin
- Min. torsional backlash (1-stage) ≤ 1 arcmin
- Max. acceleration torque 40 to 6000 Nm
- Output:
– Square housing flange with through hole (B5)
– output shaft with feather key
– smooth output shaft
– Splined shaft DIN 5480 - Input:
– Servo motor adapter
