Açısal Planet Redüktörler (PBE)
- Sizes: | 040 | 060 | 080 | 120 |
- Gear ratio range: 3 to 512
- Max. torsional backlash (2-stage): ≤ 13 to ≤ 5 arcmin
- Max. acceleration torque: 9.6 to 432 Nm
- Output:
– Housing flange with threaded hole (B14)
– output shaft with feather key
– smooth output shaft - Input end:
– Servo motor adapter
